YZ Circular Vibrating Screen

YZ Circular Vibrating Screen


Brief introduction

The moving road of screen is similar as a circle, so it is called Circular Vibrating Screen. Circular Vibrating Screen is of multilayer and high efficiency. The eccentric shaft vibration exciter and eccentric block helps to adjust amplitude. This kind of screen is of long screening stream line and more sieving specifications. So it is widely used for grading in the industries of quarry, building material, transportation, energy, chemical industry, etc.

Principle of operation

The vibrating screen uses the motor to drive the eccentric shaft to make the screen body periodically along with the direction of vibration force. The materials make circular movement on the screen to realize sieving. Circular vibrating screen consists of vibration source, screen body, screen mesh, shock absorbing device, base frame etc. It has the features of reasonable structure and long durability.



Performance features


1. It uses cylinder-type eccentric shaft and eccentric block to making strong vibrating force.
2. Beam is connected to the main body with bolts, has the feature of high strength.
3. The side plate of the screen box use the steel which make the boiler, the steel have high strength and strong impact-resistance.
4. It adopts the structure of small amplitude, high frequency, large obliquity to make the screen with high efficiency, large handing capacity, long life span, low consumption, and little noise.
